How do I set up my Wi-Fi modem?

Connect the coaxial cable
Connect the power cord
Check if your Wi-Fi modem is ready
Write down your modem's network name & password
Configure your modem
Download the Fizz Wi-Fi app



Starter Kit

The box contains the following items:

  • The Wi-Fi modem (CODA-4680)
  • A coaxial cable
  • A power cord
  • An ethernet cable



The ethernet cable is included in the box with your modem, but it is not required to set up your Wi-Fi network.

  1. Connect the coaxial cable

    The coaxial cable must be properly screwed in on both ends.

    COMMENT1

  1. Connect the power cord

    Make sure the power cord is properly connected to the Wi-Fi modem and wall outlet.

    COMMENT2

    Ideally, connect the power cord directly into the wall outlet instead of to a power strip.

    IMPORTANT: Once plugged in, your Wi-Fi modem will make its first system update. It may need to reboot after about 15 minutes.

  1. Check if your Wi-Fi modem is ready

    A series of lights will appear on your modem. Make sure they match those in this picture.

    COMMENT3

  1. Write down your modem's network name & password

    Find the network name (Default Wi-Fi Network) and password (Default Key) printed on the back of your Wi-Fi modem.

    COMMENT4

    If the network name (Default Wi-Fi Network) does not appear in the list of available networks on a Wi-Fi enabled device, it means your Wi-Fi modem's update is not complete.

    Pay close attention to characters that are similar, such as O and 0, as well as I and 1.

  1. Configure your modem

    Select the name of your Wi-Fi network from the list of networks available to your Wi-Fi enabled device and enter the password. Your Web browser will open. You will be redirected to the "Easy Connect" interface. Follow the on-screen steps.

    COMMENT5

    You may have to open your Web browser manually.

    Prefer to use your own Wi-Fi router? Click here

    If you can’t connect with the password (Default Key) shown on the back of the modem, use the Ethernet cable to connect your Wi-Fi enabled device directly into one of the modem’s ports. Follow the on-screen steps of the “Easy Connect” interface. You’ll have the opportunity to choose your own password, and you’ll be able to connect wirelessly next time.

  1. Download the Fizz Wi-Fi app

    This handy app lets you schedule pauses, manage access and more.

    Download it for free:

    To log in, use the following credentials:

    • Username: cusadmin
    • Password: (enter the new password you chose)



    There you go! Your network is now ready.

     COMMENT6
